名稱 | 型號Type | |||
YP Ⅲ-3000 | YP Ⅳ-3000 | YP V-3000 | YP VI-3000 | |
滾簡直徑 Drum diameter | 800 | 800 | 800 | 800 |
最大熨平寬度 Max ironing width | 2900 | 2900 | 2900 | 2900 |
熨平速度(m/min) Ironing speed | 0-35 | 0-40 | 0-45 | 0-50 |
熨平溫度(℃) | 158 | 158 | 158 | 158 |
蒸汽壓力(MPa) Steam pressure | 0.4-0.5 | 0.4-0.5 | 0.4-0.5 | 0.4-0.5 |
耗汽量 | 260 | 350 | 440 | 530 |
電機功率 Motor power | 2.2 | 3 | 4 | 5.5 |
變頻器功率 Frequency converter power | 2.2 | 3 | 4 | 5.5 |
電加熱功率 Electric heating power | 108 | 144 | 180 | 216 |
長(mm) L | 4100 | 4100 | 4100 | 4100 |
寬(深)(mm) W | 3140 | 4060 | 5000 | 5920 |
高 | 1360 | 1360 | 1360 | 1360 |
整機重量 Machine weight | 5800 | 7400 | 9000 | 10600 |
